| 產(chǎn)品規(guī)格 | 圖號(hào) | 偏距 | 中心孔 | 分布圓 | 螺栓孔 |
| SIZE | CODE | OFFSET | CENTER HOLE | P.C.D | BOLT HOLE |
| 8x2.5 | 08025008 | -4 | φ85.7 | φ114.3 | 5-φ10.3 |
| 8x2.5 | 08025016 | -3 | φ85.7 | φ114.3 | 5-φ15.1 |
| 8x3.75 | 08037504 | -3.5 | φ64 | φ114.3 | 5-φ15.1 |
| 8x3.75 | 08037506 | -3.5 | φ85.7 | φ114.3 | 5-φ15.1 |
| 8x3.75 | 08037507 | -3.5 | φ71.4 | φ101.6 | 4-φ15.1 |
| 8x3.75 | 08037524 | -3.5 | φ85.7 | φ114.3 | 5-φ15.1 |
| 8x3.75 | 08037525 | -3.5 | φ71 | φ101.6 | 4-φ15 |
| 8x3.75 | 08037528 | -3.5 | φ64 | φ114.3 | 5-φ15.1 |
| 8x3.75 | 08037534 | -3.5 | φ71.4 | φ114.3 | 5-φ15.1 |
| 9x4 | 09040006 | -4.5 | φ 108 | φ139.7 | 5-φ13.5 |
| 9x4 | 09040007 | -4.5 | φ85.8 | φ114.3 | 5-φ13.5 |
| 10x5 | 10050009 | -4.5 | φ106.3 | φ139.7 | 5-φ13.5 |
| 10x5 | 10050017 | 0 | φ150 | φ180 | 5-φ18 |
| 10x5.5 | 10055005 | -4 | φ101.8 | φ139.8 | 5-φ13.5 |
